Copper Alloy MIL-DTL-38999 Series Ⅲ Connectors Equipped with 4 Contacts Delivering Performance in Demanding Environments

Product Description:

The MIL-DTL-38999 Series connectors are highly reliable, rugged circular connectors designed to meet the stringent requirements of , aerospace, and other demanding applications. This particular variant features a 4-contact configuration with an insert arrangement of 15-04, specifically engineered to support coax contacts, making it an excellent choice for high-frequency signal transmission where signal integrity is paramount.

One of the defining characteristics of the MIL-DTL-38999 Series connector is its circular connector type, which provides a compact and robust solution ideal for environments where space is limited but performance cannot be compromised. The circular design facilitates easy mating and unmating while maintaining a secure connection, essential in mission-critical scenarios.

The connector utilizes a thread coupling mechanism, which ensures a secure and vibration-resistant connection. This thread coupling method not only enhances the mechanical stability of the connection but also provides ease of assembly and disassembly in the field. The threaded coupling system is designed to withstand harsh operational conditions, including shock, vibration, and extreme temperatures, commonly encountered in and aerospace environments.

Another significant feature of this MIL-DTL-38999 Series connector is its shell finish. The connector shell is coated with Olive Green Cadmium, a finish renowned for its corrosion resistance and durability. Olive Green Cadmium plating offers excellent protection against moisture, salt spray, and other corrosive elements, thereby extending the service life of the connector even in the most challenging conditions. This protective finish also contributes to the connector's overall reliability and performance, ensuring consistent connectivity over time.

The use of coax contacts within this connector configuration enables it to handle high-frequency signals with minimal loss and interference. Coax contacts are specifically designed to maintain impedance continuity and reduce signal degradation, which is crucial in applications such as radar systems, communication equipment, and other RF signal transmission scenarios. The 4-contact arrangement with insert arrangement 15-04 provides flexibility and ensures that the connector can accommodate multiple coaxial lines within a compact footprint.

In addition to its robust mechanical and electrical capabilities, the MIL-DTL-38999 Series connector is engineered for ease of use and maintenance. The circular design and thread coupling allow for quick and reliable mating, while the Olive Green Cadmium finish ensures long-term durability without the need for frequent replacement or servicing. This makes the connector an ideal choice for applications where reliability, performance, and longevity are critical.

Overall, the MIL-DTL-38999 Series connector with 4 contacts, insert arrangement 15-04, coax contacts, circular design, thread coupling, and Olive Green Cadmium shell finish represents a superior solution for high-performance, ruggedized connectivity. Its combination of mechanical strength, environmental resistance, and excellent electrical performance makes it a preferred choice for , aerospace, and other high-reliability applications requiring dependable coaxial signal transmission.

Features:

• Product Name: MIL-DTL-38999 Series
• Part Number: D38999/26WD04AN
• Connector Type: Circular
• Voltage Rating: 500V
• Insert Arrangement: 15-04
• Shell Size: 15
• Features Coax contacts for high-performance signal transmission
• Finished with Olive Green Cadmium for corrosion resistance
• Complies with MIL-DTL-38999 Series Ⅲ standards for applications
